LMS plum coupling

TIME：2017-08-21    AUTHOR：admin

Name: LMS (original MLS) type - double flanged plum - shaped flexible coupling
Description: LMS (MLS) - double flange quincunx elastic coupling is mainly composed of two closely with convex tooth meshing and radial extrusion to transfer torque, when two axis has relative offset, corresponding elastic deformation of the elastic component, automatic compensation effect.
Tags: LMZ - Ⅱ type (the original MLL - Ⅱ) with brake wheel quincunx elastic coupling LMD (the original MLZ) type single flange type plum elastic coupling
Product details:
LMS (MLS) - double flange quincunx elastic coupling is mainly composed of two closely with convex tooth meshing and radial extrusion to transfer torque, when two axis has relative offset, corresponding elastic deformation of the elastic component, automatic compensation effect.
LMS double flange plum coupling is mainly suitable for frequent starting and positive &negative, high speed, medium torque and requires high reliability of the workplace, such as: metallurgy, mining, petroleum, chemical, lifting, transportation, light industry, textile, water pump, fan, etc. Working environment temperature 35 ℃ ~ + 80 ℃, nominal torque 25 ~ 12500 nm, allowable speed of 1500 ~ 15300 r/min.
Compared with other couplings, the LMS (original MLS) type - double flanged shaped flexible coupling has the following characteristics:
(1) the work is stable and reliable, with good vibration damping, buffering and electrical insulation.
(2) simple structure, small radial dimension, light weight, small moment of inertia, suitable for medium and high speed.
(3) it has a larger axial, radial and angular compensation ability.
(4) high strength polyurethane elastic elements are resistant to oil resistance, high load capacity, long service life and safe and reliable.
(5) the coupling need not be lubricated and the maintenance workload is low, which can run continuously for a long time.


Type Tn(N.m) [n](r/min) r/min d1 d2 dz Length L       max D D1 S Kg.m Kg
Hardness Y Z/J
a b c L L1
≥75 ≥85 ≥94 Iron Steel
MLS1 16 25 45 6300 8500 12 14 32 27 92 50 90 2 0.1 2.05
16 18 19 42 30 112
20 22 24 52 38 132
MLS2 63 100 200 5200 6900 20 22 24 52 38 141 70 110 2.5 0.30 3.75
25 28 62 44 161
30 32 82 60 201
MLS3 90 140 280 4500 6000 22 24 52 38 144 85 125 3 0.57 5.15
25 28 62 44 164
30 32 35 38 82 60 204
MLS4 140 250 400 3800 5000 25 28 62 44 174 105 150 3.5 0.94 6.03
30 32 35 38 82 60 214
40 42 112 84 274
MLS5 250 400 710 3100 4100 30 32 35 38 82 60 221 125 185 4 2.4 9.35
40 42 45 48 112 84 281
MLS6 400 630 1120 2700 3600 35 38 82 60 229 145 205 4.5 5.41 16.7
40 42 45 112 84 289
48 50 55
MLS7 710 1120 2240 2300 3100 45 48 50 55 112 84 293 170 240 5.5 11.0 25
60 63 65 142 107 353
MLS8 1120 1800 3550 2000 2700 50 55 112 84 304 200 270 6.5 21.3 37
60 63 65 142 107 364
70 71 75
MLS9 1800 2800 5600 1800 2500 60 63 65 142 107 372 230 305 7.5 37.9 52
70 71 75
80 85 90 95 172 132 432
MLS10 2800 4500 9000 1600 2200 70 71 75 142 107 392 260 350 7.5 76.9 80
80 85 90 95 172 132 452
100 110 212 167 532
MLS11 4000 6300 12500 1400 1900 80 85 90 95 172 132 459 300 400 8.5 149 115
100 110 120 212 167 539
MLS12 7100 11200 20000 1200 1600 90 95 172 132 467 360 460 9 370 210
100 110 120 125 212 167 547
130 252 202 627
MLS13 8000 12500 25000 1100 1500 100 110 120 125 212 167 547 400 500 9 550 260
