T type plum blossom hexagonal pump on wheel pad

TIME：2017-08-21    AUTHOR：admin

Name: T type plum blossom hexagonal pump on wheel pad
Description: T plum hexagonal pump with the pad is applied to a shaft coupling device, is widely used in steel rolling, lifting, forging, oil and other large equipment, and other various machinery transmission shaft end connection.
Label: couplings use roller chain LA RF tire coupling tire body
Product details:
T plum hexagonal pump with the pad is applied to a shaft coupling device, is widely used in steel rolling, lifting, forging, oil and other large equipment, and other various machinery transmission shaft end connection.
Specification of the wheel pad for t-type plum blossom hexagonal pump:
Torque: 22.4 ~ 2500 nm
Wear: < 0.05 cm3/1.61 km
Product hardness: 92A + 2
Use temperature: -40 ~ 100 0 C



型號 規(guī)格
外徑（D） 內(nèi)孔直徑（D） 厚度（n） 厚度（n） 瓣數(shù)
GR19 40 18 14.5 12 6
GR24 54 26 15.2 14 8
GR28 65 30 19 15 8
GR38 80 38 22 18 8
GR42 95 46 24 20 8
GR48 104 51 25.5 20.5 8
GR55 120 60 27 22 8
GR65 135 68 32 26 8
GR75 161 81 37 30 10
GR90 199 100 42 34 10
GR100 224 111   38 10
